• Easier to drive the gate : The motor is mounted on the far end from the hinge point
  • Special sliding groove : This enables the tolerance to the unevenness of road suace up to 70 mm.
  • Unlimited opening angle : As far as the opener is concerned, the opening angle can be greater than 180 degree.
  • Automatic locking : This combines both closing and locking actions.
  • Safe and Practical: in case of power failure, the motor is equipped with a personalized releasing key
  • Manual Release option with customized key
  • Non –Corrosive stainless steel base plate.
Power supply 220 V AC / 50 Hz
Motor power 100 W * 2 nos
Motor Voltage DC 24 V
Gate moving speed 10 – 15 m / min
Maximum weight of gate 600 + 600 Kg
Remote control distance ≥ 50 m
Limit switch Magnet
RPM 2800
Motor Force 1000 N
Working temperature -20°C ~ +70°C
Protection Class IP 54
