Features
- Special design with all-in-one rain cover
- Metal Panel
- Metal button
- 700TVL color camera
- 53°viewing angle
- LED white light night vision
- Weatherproof IP66
- Surface mount
Specification:
|
NO.
|
ITEMS
|
CONTENT |
|
1
|
Subscribers quantity
|
1 |
|
2
|
Material
|
Metal alloy
|
|
3
|
Camera
|
1/4 inch CMOS color, 700TVL
|
|
4
|
Viewing angel |
53°
|
|
5
|
Night vision
|
LED white light
|
|
6
|
Minimum illumination
|
0 LUX (0.5meter)
|
|
7
|
Weather proof
|
IP44
|
|
8
|
Power Supply
|
DC11 -13V
|
|
9
|
Power Consumption (workingmode)
|
2.5W (Max.),1W (standby)
|
| 10 |
Support lock type
|
DC5-24V electric lock,currency less than 4A.
|
| 11 |
Extend lock
|
Support 1(Need NC05 for connection)
|
| 12 |
Distance (indoorto outdoor)
|
60m(RVV4x0.5)100m(RVV3*0.5+SYV75-3)
|
| 13 |
Installation
|
Surface mount
|
| 14 |
Dimension
|
160*48*29mm
|
| 15 |
Working Temperature
|
-25ºC to +60ºC
|
| 16 |
Storage Temperature
|
-30ºC to +60ºC
|
